W&C compounds feature balanced electrical and mechanical properties as well as extrusion processability. They are used in insulating and sheathing electric and communication cables.
Hanwha Solutions Wire & Cable Brochure
download-
Wire & Cable Business
-
Wire & Cable Products
Polyolefin
-
HV Power Cable Insulation
ProductCLNB-8141S
- Characteristics
- Excellent Scorch Stability
Superior Electrical Property
Good Heat Resistance
Excellent Crosslinking Characteristics - Applications
- MV Power Cable Insulation (up to 69kV)
ProductCLNA TR-8142EC
- Characteristics
- Excellent Scorch Property
Good Heat Resistance
Excellent Crosslinking Characteristics - Applications
- Tree Retardant for XLPE MV Cable Insulation(Up to 69kV)
ProductCLNA-8141SC
- Characteristics
- Excellent Scorch Property
Superior Electrical Property
Good Heat Resistance
Excellent Crosslinking Characteristics - Applications
- HV Power Cable Insulation(Up to 161kV)
ProductCLNA-8141EHV
- Characteristics
- extremely low level of contamination and proper balance of non-staining antioxidant and peroxide to ensure thermal stability and optimum cure levels
- Applications
- EHV Power Cable Insulation(up to 220 kV)
ProductCLNA-8141SEHV
- Characteristics
- extremely low level of contamination and proper balance of non-staining antioxidant and peroxide to ensure thermal stability and optimum cure levels
- Applications
- EHV Power Cable Insulation(Over 220kV)
-
Semi-conductive Shield
ProductCTBA-8720BK
- Characteristics
- Excellent Processability
Good Electrical Properties
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shied for MV(Up to 69kV) Cable
ProductCTBA-8730BK
- Characteristics
- Excellent Processability
Good Electrical Properties
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shied for MV(Up to 69kV) Cable
ProductCTBB-8720BK
- Characteristics
- Excellent Processability
Good Electrical Properties
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shied for MV(Up to 69kV) Cable
ProductCTBB-8730BK
- Characteristics
- Excellent Processability
Good Electrical Properties
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shied for MV(Up to 69kV) Cable
ProductCTBA-8740BK
- Characteristics
- Excellent Electrical Properties
Excellent Surface Smoothness
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shied for HV(up to 161kV) Cable
ProductCTBA-8745BK
- Characteristics
- Excellent Electrical Properties
Excellent Surface Smoothness
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shield for EHV Cable (up to 220kV)
ProductCTBA-8750BK
- Characteristics
- Excellent Electrical Properties
Excellent Surface Smoothness
Excellent Crosslinking Characteristics
Good Heat Resistance - Applications
- Conductor and Bonded Insulation Shield for SEHV Cable
(Over 220kV)
ProductCTBA-8760BK
- Characteristics
- Excellent Electrical Properties
Excellent Surface Smoothness
Excellent Crosslinking Characteristics
Scorch Stability
Excellent Space Charge Properties - Applications
- Conductor and Insuation Shield for DC Cable
(Up to 525kV)
ProductCCBA-8715BK
- Characteristics
- Excellent Electrical Properties
Good Surface Smoothness
Easy Strippable - Applications
- Strippable Insulation Shield for MV(Up to 46kV) EPR and XLPE Cable
ProductCCBA-8725BK
- Characteristics
- Excellent Electrical Properties
Good Protrusion Characteristics
Easy Strippable - Applications
- Strippable Insulation Shield for MV(Up to 69kV) Cable
-
Submarine Power Cable Insulation
ProductCLNS-8141SC
- Characteristics
- Excellent Long-run Processability
Superior Electrical Property
Excellent Scorch Property - Applications
- HV Submarine Power
Cable Insulation
(up to 161kV)
ProductCLNS-8141EHV
- Characteristics
- Excellent Long-run Processability
Superior Electrical Property
Excellent Scorch Property - Applications
- EHV Submarine Power
Cable Insulation
(up to 220kV)
-
Outdoor Cable Insulation
ProductCLBA-8923BK
- Characteristics
- Excellent Tracking Resistance
Good Processability and Scorch Stability
Good Heat Stability and Weather Resistivity
Good Electrical and Cure Properties - Applications
- Black XLPE for Outdoor Cable Insulation(Up to 36kV)
ProductCLBB-8923BK
- Characteristics
- Good Processability and Scorch Stability
Good Heat Stability and Weather Resistivity
Good Tracking Resistance
Good Electrical and Cure Properties - Applications
- Black XLPE for Outdoor Cable Insulation(Up to 36kV)
-
Jacketing Compound
ProductCLBB-850BK
- Characteristics
- Excellent stress crack resistance(ESCR)
Excellent processability
Excellent weathering resistance
Good physical properties - Applications
- LDPE Jacketing for Power/Telecommunication Cable
ProductCLBA-8450BK
- Characteristics
- Superior processability
Excellent stress crack resistance(ESCR)
Excellent weathering resistance
Low shrinkage - Applications
- HDPE Jacketing for power/telecommunication cable (black)
ProductCMBA-8240BK
- Characteristics
- Excellent stress crack resistance(ESCR)
Good abrasion & scratch resistance
Excellent weathering resistance
Good processing characteristics - Applications
- LLDPE jacketing for power/telecommunication cable (black)
-
Telecommunication Cable Compound
ProductHDPE-8380
- Characteristics
- excellent processability, environmental and thermal stress cracking resistance
- Applications
- Skin/solid HDPE for LAN insulation
ProductHDPE-8380L
- Characteristics
- High drawability
- Applications
- Skin/solid HDPE for LAN insulation
-
LV Power Cable Insulation
